One popular way to structure screens in Android applications is to dedicate a top-level Fragment to each screen. Then, to switch between screens, you replace the currently visible Fragment with another Fragment.
In my previous post I explained the architectural significance of properly designed navigation logic. If you haven’t read it yet, I recommend that you do that now. In this follow-up article I’ll show you how to implement ScreenNavigator abstractions described in the previous post. In addition, I want to give a shout-out to FragNav library which is amazing, but not widely known tool.
Why You Need Third-Party Library for Navigation between Fragments
I’ve been working with Fragments since I decided to become an Android developer. What I can tell you after all these years is that Fragments are tricky beasts. The most difficult thing about Fragments is their lifecycle, of course, but navigation between Fragments isn’t that straightforward either.
To replace a Fragment in some container ViewGroup you can use the following code:
getSupportFragmentManager() .beginTransaction() .replace(R.id.fragment_container, fragment) .commit();
That’s not difficult. However, Fragment transactions won’t be added to backstack by default, so you won’t be able to navigate back to the previous screen. To enable back-navigation, you’d do something like this:
getSupportFragmentManager() .beginTransaction() .addToBackStack(null) .replace(R.id.fragment_container, fragment) .commit();
Then you can go back using this logic:
getSupportFragmentManager().popBackStack();
In some cases, you might want to clear all other backstacked Fragments before you navigate to the next one. This code achieves that:
getSupportFragmentManager().popBackStack(null, FragmentManager.POP_BACK_STACK_INCLUSIVE);
So, you can handle Fragments navigation manually, but it might be tricky. In addition, there are some edge cases that you wouldn’t know about until you run into them. Therefore, instead of dealing with all these complications yourself, you can just use a third-party lib that implements the required functionality.
One such third-party lib is FragNav, and it’ll be the main focus of this article.
Set Up FragNav
FragNav library exposes most of its functionality through a class called FragNavController. This class is stateful, which means that you can’t create a new instance in each Fragment (because they won’t share the same state). Therefore, you need to make sure that all navigation clients within the scope of each specific Activity use the same instance of FragNavController.
The most effective way of achieving the above requirement would be to use proper dependency injection in your application. Then you can make FragNavController so-called Activity-scoped object. If you don’t use dependency injection, then just instantiate FragNavController inside Activity and make sure that all navigation calls are delegated to it. Note that when I say “all calls”, I also mean calls from Fragments and other components which reside within that Activity.
Once you’ve got FragNavController scoped to Activity, construct ScreenNavigator abstraction in this manner:
public class ScreensNavigator { private final FragNavController mFragNavController; public ScreensNavigator(FragNavController fragNavController) { mFragNavController = fragNavController; } }
Before we use FragNavController, it must be initialized. Add init() method to ScreenNavigator and put this logic into it:
public void init(Bundle savedInstanceState) { mFragNavController.setRootFragmentListener(mRootFragmentListener); mFragNavController.initialize(FragNavController.TAB1, savedInstanceState); }
Then call this new init() method from onCreate() method of each of your Activities that will use ScreenNavigator:
@Override protected void onCreate(@Nullable Bundle savedInstanceState) { ... mScreensNavigator.init(savedInstanceState); }
Please note how I pass savedInstanceState Bundle as a parameter. This is crucially important to do for the navigation to work properly across configuration changes and process death. However, to make sure that this Bundle contains FragNavController’s state, you’ll need to add additional method to ScreenNavigator:
public void onSaveInstanceState(Bundle saveInstanceState) { mFragNavController.onSaveInstanceState(saveInstanceState); }
Call this method from onSaveInstanceState() method of each of your Activities that will use ScreenNavigator:
@Override public void onSaveInstanceState(Bundle saveInstanceState) { super.onSaveInstanceState(saveInstanceState); mScreensNavigator.onSaveInstanceState(saveInstanceState); }
This completes the minimal setup for FragNavController.
Define The Root Fragment
If you ever implemented manual navigation between Fragments, you surely know this pattern in Activity’s onCreate() method:
if (savedInstanceState == null) { getSupportFragmentManager() .beginTransaction() .addToBackStack(null) .replace(R.id.fragment_container, FirstFragment.newInstance()) .commit(); }
I check whether the Activity is created for the first time (that’s the meaning of savedInstanceState being null), and, if it is, I navigate to the very first Fragment.
FragNavController takes care of this check for you. You just need to tell it which Fragment is the first one. In terms of FragNav, that first Fragment is called “root Fragment”. The way you define root Fragment is using RootFragmentListener. Inside init() method I already set mRootFragmentListener on FragNavController, but I haven’t shown you its implementation yet. That’s it:
private FragNavController.RootFragmentListener mRootFragmentListener = new FragNavController.RootFragmentListener() { @Override public int getNumberOfRootFragments() { return 1; } @NotNull @Override public Fragment getRootFragment(int index) { switch (index) { case FragNavController.TAB1: return RootFragment.newInstance(); default: throw new IllegalStateException("unsupported tab index: " + index) } } };
At this point, you might ask yourself what’s the reason for this approach and why there is this TAB1 constant there. I’ll write about tabs a bit later, but, in short, FragNav supports bottom tab navigation out of the box. Therefore, even if you don’t have bottom tabs, you’ll need to kind of pretend that you do have one tab when you use FragNav.
After you define the root Fragment this way, your application will start and show this Fragment right away.
Navigate Between Fragments
Until now, you wrote quite a bit of code to set up FragNav in your app and then show the first Fragment. Was all this complexity justified? Yes, it was, because now, whenever you need to navigate to another Fragment, you can just add a very simple method to ScreenNavigator:
public void toProductDetails(Product product) { mFragNavController.pushFragment(ProductDetailsFragment.newInstance(product)); }
That’s it. Call this method from other clients and you’ll get to this screen.
Back Navigation
To navigate back to the previous screen, add this method to ScreenNavigator’s API:
public boolean navigateBack() { if(mFragNavController.isRootFragment()) { return false; } else { mFragNavController.popFragment(); return true; } }
Then override onBackPressed() in your Activities and put this kind of logic in there:
@Override public void onBackPressed() { if (mViewMvc.isDrawerVisible()) { mViewMvc.closeDrawer(); } else if (!mScreensNavigator.navigateBack()) { super.onBackPressed(); } }
Nice!
Clear Previously Shown Fragments Stack
In some situations, you want to navigate to a Fragment while clearing the “history” of navigation, so the user won’t be able to go back. For example, this pattern is often used for applications’ main screens.
That’s how you’d do it with FragNav:
public void toHome() { mFragNavController.clearStack(); mFragNavController.pushFragment(HomeFragment.newInstance()); }
Beautiful!
Bottom Tab Navigation
As I already told you, FragNav supports bottom tabs navigation out of the box. Not only that, it also keeps separate Fragments backstacks for all your tabs. That’s very advanced functionality that would be extremely difficult to implement manually, but it becomes a breeze with FragNav.
To use more than one tab in your app, just go back to RootFragmentListener and declare that you’ll have more than one root Fragment:
private FragNavController.RootFragmentListener mRootFragmentListener = new FragNavController.RootFragmentListener() { @Override public int getNumberOfRootFragments() { return 3; } @NotNull @Override public Fragment getRootFragment(int index) { switch (index) { case FragNavController.TAB1: return RootFragment1.newInstance(); case FragNavController.TAB2: return RootFragment2.newInstance(); case FragNavController.TAB3: return RootFragment3.newInstance(); default: throw new IllegalStateException("unsupported tab index: " + index) } } };
As you see, I also create association between tabs and their respective root Fragments.
After that, all you’ve got to do to navigate to other tabs is add methods similar to the below two to ScreenNavigator:
public void toMainTab() { mFragNavController.switchTab(FragNavController.TAB1); } public void toSettings() { mFragNavController.switchTab(FragNavController.TAB2); }
Now just call these methods in response to user clicks on one of the bottom tabs.
Summary
In this post I demonstrated how you can implement ScreenNavigator using FragNav library. You probably noticed that I’m very impressed with it, but just in case you didn’t, let me state it explicitly: FragNav is amazing.
In my opinion, the elegance of FragNav’s API is comparable to these of OkHttp and Retrofit. All these libraries address complex tasks, but allow you to perform these complex tasks using simple, elegant and powerful APIs. You’ve already seen the simplicity and elegance of FragNav, but I should probably mention its power and flexibility as well.
FragNav is highly configurable and includes some tricks and optimizations that I wouldn’t even think about. You want to allow state loss on all Fragment transactions? This is just one line of code with FragNav. Maybe you want to eagerly pre-instantiate all root Fragments to make switch between tabs quicker? This too is just one line of code. Or, maybe, you’re so obsessed with performance that you don’t want to perform fragment transactions when you switch tabs and would prefer to just show/hide individual Fragments instead? Yes, even such a crazy use case is just one line of code! And this list of configurations if far from being complete.
When I just began my Android journey I wrote all the Fragments management logic manually in each place. It was ugly and led to massive code duplication. Then I realized that I can extract most of this code into base classes for my Activities and Fragments, thus reducing duplication. Later I learned that composition and dependency injection are preferable to inheritance in most cases, so I further extracted this logic into FragmentHelper class and copy-pasted it between my projects. That worked alright, but, sure enough, I discovered bugs in FragmentHelper along the way and wanted to fix them. It was tedious work and, in some cases, it was impossible to do because I wasn’t involved in some project anymore. Therefore, I decided to make FragmentHelper into a proper library. This made the maintenance simpler on my side, and developers who took over my past projects would get standard notifications about new versions.
I was quite happy with FragmentHelper and even considered adding new advanced features. However, last year I started a new Android application which used bottom tabs. The other developer on that project proposed to use FragNav instead of my FragmentHelper. The moment we integrated this library, I immediately knew that I won’t use my FragmentHelper library ever again. So, after investing years, literally, into my own library for Fragment navigation, I deprecated it in the blink of an eye when I learned about FragNav. Today, I think that all Android developers who work with Fragments should be at least aware of its existence.
As always, thanks for reading and don’t forget to subscribe for my newsletter if you liked this article.
